What is Hinge Generator (Maochen)?
Hinge Generator is a free MakerWorld customizer by Maochen that makes screw-on leaf hinges in the size you need, printed in one piece with the pin already inside. It runs on a Fusion file in MakerWorld's Customize panel, so no CAD is needed. Since it went up in December 2025 it has been customized more than 20,000 times and has over 6,000 likes.
A labeled photo on the page shows what each of the eight settings controls: hinge length, width and thickness, knuckle outer diameter, pin diameter, screw hole diameter, and the spacing between the holes in both directions. The four screw holes are countersunk. The author says the pin gap is fixed at 0.3 mm, so a hinge that sticks after printing may need a firm first bend. Updates in May and June 2026 let the leaves fold back to 270 degrees, now also on hinges 3 mm thick or less. For common sizes, seven sample hinges from 30 by 40 mm up to 102 by 80 mm come as STL files with a Bambu print profile.
It is free with a MakerWorld account, but the MakerWorld Exclusive License does not allow selling the prints. It suits anyone fixing a cabinet, adding a lid to a box or building a jig with a hinge that fits their screws.
What you can make
- Screw-on leaf hinges
- Small cabinet and door hinges
- Lid hinges for boxes and cases
- Hinges that fold back to 270 degrees
How to use Hinge Generator
- Open the model on MakerWorld and click Customize
- Enter the hinge length, width and thickness in mm
- Set the knuckle and pin diameters, then the screw hole size and spacing
- Log in, click Generate, check the preview and download the file
- Print it, bend the hinge once to free the pin, then screw the leaves in place
What you'll need to print it
Filament and parts that suit what you make with Hinge Generator.
M3 screws
PETG
M3 heat-set inserts
Also handy
Some of these are affiliate links: we may earn a small commission, at no extra cost to you. More about that
Hinge Generator pros
- A labeled photo explains every one of the eight measurements
- Screw hole size and spacing can be matched to the hardware you already have
- Prints in one piece with the pin in place, and seven sample sizes come with a Bambu print profile
Hinge Generator cons
- Always four screw holes and a fixed 0.3 mm pin gap; neither can be changed
- The author notes Generate sometimes needs a few clicks before the model changes
- MakerWorld Exclusive License: no selling prints or sharing outside MakerWorld
